المواصفات
| Product Model | Flexx Junior | ||
| Nominal seat width (in) | 10 ~ 14 | 10 ~ 14 | 10 ~ 14 |
| Caster x Rear wheel size (in) | 5/6 x 14 | 5/6 x 20 | 5/6 x 22 |
| Maximum user weight (kg) | 75 | 75 | 75 |
| Overall length with legrest (mm) | 820 ~ 835 | 830 ~ 900 | 840 ~ 890 |
| Overall width (mm) | 450 ~ 550 | 485 ~ 590 | 485 ~ 590 |
| Overall height (mm) | 800 ~ 850 | 780 ~ 830 | 825 ~ 875 |
| Folded length (mm) | 810 ~ 870 | 810 ~ 870 | 810 ~ 870 |
| Folded width (mm) | 325 | 355 | 355 |
| Folded height (mm) | 725 | 725 | 725 |
| Total mass (kg) | 14.3 ~ 14.4 | 14.9 ~ 15.0 | 15.2 ~ 15.3 |
| Mass of the heaviest part (kg) | 9.7 ~ 9.8 | 9.4 ~ 9.5 | 9.4 ~ 9.5 |
| Handrim diameter (mm) | N/A | 430 | 480 |
| Horizontal location of axle (mm) | 60 ~ 100 | 0 | 0 |
| Minimum turning radius (mm) | 695 ~ 755 | 610 ~ 700 | 620 ~ 710 |
| Minimum turning radius without user (mm) | 605 ~ 650 | 515 ~ 610 | 530 ~ 610 |
| Pivot width (mm) | 950 ~ 980 | 960 ~ 1050 | 970 ~ 1040 |
| Static stability downhill (X°) | 15 | 15 | 15 |
| Static stability uphill (X°) | 14 | 14 | 14 |
| Static stability uphill with anti-tippers (X°) | N/A | N/A | N/A |
| Static stability sideways (X°) | 14 | 14 | 14 |
| Seat plane angle (X°) | 5 | 5 | 2 |
| Effective seat depth (mm) | 315 ~ 395 | 315 ~ 395 | 315 ~ 395 |
| Nominal seat depth (mm) | 285 ~ 365 | 285 ~ 365 | 285 ~ 365 |
| Effective seat width (mm) | 250 ~ 350 | 250 ~ 350 | 250 ~ 350 |
| Seat surface height at front edge (mm) | 410 | 400 | 415 |
| Backrest angle (X°) | 11 ~ 31 | 13 ~ 33 | 9 ~ 29 |
| Seat to backrest angle (X°) | 97 ~ 117 | 98 ~ 118 | 97 ~ 117 |
| Backrest height (mm) | 380 | 380 | 380 |
| Headrest height above seat (mm) | N/A | N/A | N/A |
| Leg to seat angle (X°) | 94 | 94 | 94 |
| Footrest to seat distance (mm) | 150 ~ 250 | 150 ~ 250 | 150 ~ 250 |
| Armrest to seat distance (mm) | 155 ~ 235 | 180 ~ 235 | 220 ~ 235 |
| Front location of armrest structure (mm) | 270 | 270 | 270 |
Remark : Karma reserves the right to modify information herein without further notice.
