Frame Colors
Specification
| Product Model | SME | ||
| Nominal seat width (mm)* | 400 | 440 | 480 |
| Nominal seat depth (mm)** | 400 | 440 | 480 |
| Front caster / Rear wheel size (in) | 6 / 24 | 6 / 24 | 6 / 24 |
| Backrest height (mm) | 415 | 415 | 415 |
| Headrest height above seat (mm) | N/A | N/A | N/A |
| Armrest to seat distance (mm) | 170 ~ 210 | 170 ~ 210 | 170 ~ 210 |
| Front location of armrest structure (mm) | 0 ~ 310 | 0 ~ 310 | 0 ~ 310 |
| Seat surface height at front edge (mm) | 490 | 490 | 490 |
| Footrest to seat distance (mm) | 350 ~ 410 | 350 ~ 410 | 350 ~ 410 |
| Effective seat width (mm) | 400 | 440 | 480 |
| Effective seat depth (mm) | 455 | 485 | 515 |
| Seat plane angle (X°) | 1 | 1 | 1 |
| Backrest angle (X°) | 10 | 10 | 10 |
| Seat to backrest angle (X°) | 99 | 99 | 99 |
| Leg to seat angle (X°) | 92 | 92 | 92 |
| Overall length with legrest (mm) | 1005 ~ 1060 | 1005 ~ 1060 | 1005 ~ 1060 |
| Overall width (mm) | 590 | 630 | 670 |
| Overall height (mm) | 950 | 950 | 950 |
| Folded length (mm) | 1015 | 1015 | 1015 |
| Folded width (mm) | 535 | 580 | 625 |
| Folded height (mm) | 600 | 600 | 600 |
| Total mass (kg) | 27.4 | 29.8 | 32.0 |
| Mass of the heaviest part (kg) | 18.8 | 21.0 | 23.2 |
| Maximum user weight (kg) | 120 | 120 | 120 |
| Minimum turning radius (mm) | 790 | 790 | 790 |
| Minimum turning radius without user (mm) | 750 | 750 | 750 |
| Pivot width (mm) | 1130 | 1130 | 1130 |
| Static stability downhill (X°) | 8 | 8 | 8 |
| Static stability uphill (X°) | 10.1 (with anti-tippers) | 10.1 (with anti-tippers) | 10.1 (with anti-tippers) |
| Static stability sideways (X°) | 18 | 18 | 18 |
| Handrim diameter (mm) | 525 | 525 | 525 |
| Horizontal location of axle (mm) | 40 ~ 100 | 40 ~ 100 | 40 ~ 100 |
| Battery capacity (Ah) | 2.9*2 | 2.9*2 | 2.9*2 |
| Charger output current (A) | 1 | 1 | 1 |
Manual ver.13
Remark :
* Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
** Nominal seat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
– The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
– The actual product specifications may vary according to different configurations.
– KARMA reserves the right to modify information herein without further notice.
