Optional Accessories
2-in-1 Lighting
Swing-away Controller Bracket
Handle Bar
Tray Table
Elevating Legrest with Calf Support
Ship-shape Wide Armpad
Push Brake
Side Frame Colors
| Product Model | KP-31.2CPT | |
| Nominal seat width (mm/in)* | 450 / 18 | 475 / 20 |
| Nominal seat depth (mm/in)** | 440 / 18 | 490 / 20 |
| Front caster / Drive wheel size (in) | 9 / 14 | 9 / 14 |
| Backrest height (mm) | 535 | 535 |
| Headrest height above seat (mm) | 607 ~ 682 | 655 ~ 700 |
| Armrest to seat distance (mm) | 180 ~ 280 | 175 ~ 272 |
| Front location of armrest structure (mm) | 230 ~ 645 | 230 ~ 645 |
| Seat surface height at front edge (mm) | 565 | 553 |
| Footrest to seat distance (mm) | 415 ~ 535 | 390 ~ 530 |
| Effective seat width (mm) | 470 | 500 |
| Effective seat depth (mm) | 420 ~ 500 | 490 ~ 570 |
| Seat plane angle (X°) | 11 | 7 |
| Backrest angle (X°) | -79 ~ 56 | -84 ~ 47 |
| Seat to backrest angle (X°) | 0 ~ 134 | 0 ~ 131 |
| Leg to seat angle (X°) | 100 | 105 |
| Overall length with legrest (mm) | 1060 ~ 1130 | 1060 ~ 1130 |
| Overall width (mm) | 600 | 625 |
| Overall height (mm) | 1210 ~ 1250 | 1260 ~ 1305 |
| Folded length (mm) | 855 | 855 |
| Folded width (mm) | 600 | 625 |
| Folded height (mm) | 750 ~ 810 | 750 ~ 810 |
| Total mass (kg) | 108 | 108.5 |
| Total mass without batteries (kg) | 77.4 | 77.9 |
| Mass of the heaviest part (kg) | 70.0 | 70.5 |
| Maximum user weight (kg) | 136 | 136 |
| Motor power (W) | 350 | 350 |
| Battery capacity (Ah) | 50*2 | 50*2 |
| Charger output current (A) | 6 / 8 | 6 / 8 |
| Drive range (km)*** | 27 | 27 |
| Battery Compartment (L x W x H) (mm) | 397.5 x 175 x 170 | 397.5 x 175 x 170 |
| Maximum speed forward (km) | 10 | 10 |
| Minimum braking distance from max speed (mm) | 2100 | 2100 |
| Obstacle climbing (mm) | 50 | 50 |
| Ground clearance (mm) | 73 | 73 |
| Minimum turning radius (mm) | 1020 | 1020 |
| Minimum turning radius without user (mm) | 825 | 825 |
| Reversing width (mm) | 1145 ~ 1265 | 1145 ~ 1265 |
| Static stability downhill (X°) | 14 | 14 |
| Static stability uphill (X°) | 15 | 15 |
| Static stability sideways (X°) | 14 | 14 |
| Dynamic stability uphill (X°) | 6 | 6 |
| Ability to climb rated slope (X°)*** | 12 | 12 |
Remark :
* Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
** Nominal seat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
*** Drive range/ Ability to climb rated slope are estimated based on the following conditions: 20℃~35℃, 136 kg occupant, brand new fully charged batteries and driving on the flat road.
– The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
– The actual product specifications may vary according to different configurations.
– KARMA reserves the right to modify information herein without further notice.
