Specification
| Product Model | KS-343.2S | |
| Nominal seat width (mm/in)* | 425 / 17 | 425 / 17 |
| Nominal seat depth (mm/in)** | 420 / 17 | 420 / 17 |
| Front caster / Drive wheel size (in) | 10 / 10 | 11 / 11 |
| Backrest height (mm) | 490 | 490 |
| Headrest height above seat (mm) | 585 ~ 650 | 580 ~ 645 |
| Armrest to seat distance (mm) | 190 | 190 |
| Front location of armrest structure (mm) | 760 ~ 1070 | 760 ~ 1070 |
| Seat surface height at front edge (mm) | 592 ~ 642 | 600 ~ 650 |
| Footrest to seat distance (mm) | 400 ~ 450 | 400 ~ 450 |
| Effective seat width (mm) | N/A | N/A |
| Effective seat depth (mm) | 420 | 420 |
| Seat plane angle (X°) | 7.5 | 7.5 |
| Backrest angle (X°) | 19 | 19 |
| Seat to backrest angle (X°) | 101.5 | 101.5 |
| Leg to seat angle (X°) | 90 | 90 |
| Overall length with legrest (mm) | 1180 ~ 1280 | 1180 ~ 1280 |
| Overall width (mm) | 600 ~ 680 | 600 ~ 680 |
| Overall height (mm) | 1192 ~ 1312 | 1200 ~ 1320 |
| Folded length (mm) | 1180 | 1180 |
| Folded width (mm) | 600 | 600 |
| Folded height (mm) | 672 | 680 |
| Total mass (kg) | 91.1 (36Ah) 99.1 (50Ah) | 93.7 (36Ah) 101.7 (50Ah) |
| Total mass without batteries (kg) | 68.5 | 71.1 |
| Mass of the heaviest part (kg) | 49.4 | 52 |
| Maximum user weight (kg) | 136 | 136 |
| Motor power (W) | 470 | 470 |
| Battery capacity (Ah) | 36 x 2 50 x 2 (optional) | 36 x 2 50 x 2 (optional) |
| Charger output current (A) | 5 | 5 |
| Drive range (km)*** | 25 (36Ah) 32 (50Ah) | 28 (36Ah) 37 (50Ah) |
| Battery Compartment (L x W x H) (mm) | 210 x 170 x 180 (Single Compartm ent) |
|
| Maximum speed forward (km) | 9 | 10 |
| Minimum braking distance from max speed (mm) | 1800 | 2100 |
| Obstacle climbing (mm) | 75 | 75 |
| Ground clearance (mm) | 45 | 45 |
| Minimum turning radius (mm) | 1600 | 1600 |
| Reversing width (mm) | 1800 | 1800 |
| Static stability downhill (X°) | 15 | 15 |
| Static stability uphill (X°) | 15 | 15 |
| Static stability sideways (X°) | 14 | 14 |
| Dynamic stability uphill (X°) | 6 | 6 |
| Ability to climb rated slope (X°)*** | 10 | 10 |
ver.02
Remark：
* Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
* Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
** Nominal seat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
*** Drive range/ Ability to climb rated slope are estimated based on the following conditions: 20℃~35℃, 135kg occupant, brand new fully charged batteries and driving on the flat road.
– The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
– The actual product specifications may vary according to different configurations.
– Karma reserves the right to modify information herein without further notice
